IE1-EG Electric motor 15 kW, 230/400 Volt 1500 RPM
€1,149.09
In stock
IE1-EG Electric motor 15 kW, 230/400 Volt with foot-flange mounting B3-B5, 1500 RPM
- Extremely suitable as an engine for a hydraulic power unit
- To be used in combination with a lantern piece
- Equipped with mounting bracket (B3)
Technical features:
- Engine type: EG160 L4
- Build Size: 160L
- Material: cast iron
- Voltage: 230/400 Volts (50 Hz)
- Power: 15 kW / 20.5 hp
- Shaft: 42mm with keyway
- Flange diameter: 300mm
- Torque: 98.1 Nm
- Speed: 1460RPM
- Noise Level: 79dB
- Weight: 142 kg
- Foot type: B3
- Flange type: B5
- For further specifications see spec sheet 1.
Dimensions technical drawing (in mm):
| a | 254 | k | 15 | d | 42 | p | 350 |
| AA | 73 | KK | 2-M40X1.5 | DB | M16X36 | N | 250 |
| AB | 320 | l | 714 | E | 110 | m | 300 |
| AC | 330 | f | 12 | s | 19 | ||
| B | 254 | G | 37 | T | 5 | ||
| BB | 362 | LA | 15 | ||||
| C | 108 | ||||||
| huh | 160 | ||||||
| HA | 20 | ||||||
| HD | 420 |
For further detailed technical drawing see spec sheet 2.
