IE1 Electric motor 0.75 kW, 230/400 Volt 1500 RPM
€162.05
In stock
IE1 Electric motor 0.75 kW, 230/400 Volt with foot flange mounting B3-B5, 1500 RPM
- Extremely suitable as a motor for a hydraulic unit
- To be used in combination with a lantern piece
- Equipped with mounting bracket (B3)
Technical properties:
- Motor type: MS80 2-4
- Construction size: 80
- Material: aluminum
- Voltage: 230/400 Volt (50 Hz)
- Power: 0.75 kW / 1 hp
- Axle: 19 mm with keyway
- Flange diameter: 200 mm
- Torque: 5.19 Nm
- Speed: 1380 RPM
- Noise level: 58 dB
- Weight: 10 kg
- Foot type: B3
- Flange type: B5
- For further specifications see specs sheet 1.
Technical drawing dimensions (in mm):
| a | 125 | TBS | 27 | D | 19 | M | 165 |
| AA | 160 | TBW | 105 | E | 40 | N | 130 |
| AC | 163 | TBH | 105 | F | 6 | P | 200 |
| b | 100 | G | 15.5 | S | 12 | ||
| c | 50 | SS | M6 | T | 3.5 | ||
| H | 80 | XX | 16 | ||||
| HD | 213 | ZZ | 21 | ||||
| K | 10x13 | ||||||
| KK | 1-M20x1.5 | ||||||
| L | 290 |
For further detailed technical drawings see specs sheet 2.
