IE1 Electric motor 5.5 kW, 230/400 Volt 1500 RPM
€510.57
In stock
IE1 Electric motor 5.5 kW, 230/400 Volt with foot-flange mounting B3-B5, 1500 RPM
- Extremely suitable as an engine for a hydraulic power unit
- To be used in combination with a lantern piece
- Equipped with mounting bracket (B3)
Technical features:
- Engine type: MS132 S-4
- Build Size:
- engine type:
- Build Size: 132S
- Material: aluminum
- Voltage: 230/400 Volts (50 Hz)
- Power: 5.5 kW / 6.8 hp
- Shaft: 38mm with keyway
- Flange diameter: 300mm
- Torque: 36.22 Nm
- Speed: 1450RPM
- Noise level: 71 dB
- Weight: 40 kg
- Foot type: B3
- Flange type: B5
- For further specifications see spec sheet 1.
Dimensions technical drawing (in mm):
| a | 216 | TBS | 38 | d | 38 | m | 265 |
| AA | 252 | TBW | 112 | E | 80 | N | 230 |
| AC | 265 | TBH | 112 | f | 10 | p | 300 |
| B | 140 | G | 33 | s | 15 | ||
| C | 89 | SS | M12 | T | 4 | ||
| huh | 132 | XX | 28 | ||||
| HD | 318 | ZZ | 37 | ||||
| k | 12x15 | ||||||
| KK | 2-M25x1.5 | ||||||
| l | 437 |
For further detailed technical drawing see spec sheet 2.
