NG10 12V Cetop Electric 4/2 control valve | H-middle position | Spool 41A

NG10 12V Cetop Electric 4/2 control valve | H-middle position | Spool 41A

• control valve type: 4/2
• Package contents: cetop plug, cetop valve and 4xM6 mounting bolts

Technical specifications:

• actuation: electric
• Cetop model: NG10
• Voltage: 12 VDC
• Spool: H-middle position (spool 41a)
• Max. oil flow: 120 l/min
• Max. pressure: 315 bar
• operating pressure A, B, P: 315 bar
• operating pressure T: 160 bar
• Ø core (nucleus): 31.4mm
