Portable proportional control with 11 PWM outputs and 6 levers including receiver
€3,695.00
In stock
Portable proportional control with 11 PWM outputs and 6 levers including receiver
Compact joystick radio control with 11 PWM outputs and 6 levers with internal antenna that can easily be hung to carry and operate at the waist. Includes receiver that can be connected to the machine to be controlled.Technical specifications:
- Brand: Elca
- Dimensions: 275x170x180mm
- Ingress protection (IP rating) control box: IP65
- Control box weight: 1.1kg
- Working distance wireless: 150m
- Including receiver with cable protection (8-30 Vdc)
- Receiver Ingress protection (IP rating): IP67
- Receiver dimensions: 220x200x75mm
- With removable activation key
- Start and emergency stop button
- 6 levers
- 11 PWM exits
- 7 tumblers
- 4x 3 positions 1-0-1 spring return switch
- 2x 2-position 0-1 switch
- Including charger LI-TE ION 12-30 Vdc
- Includes 2 rechargeable ones batteries LI-TE Li-Ion 7.4V 2.2Ah
- Operating temperature: -20 °c up to +50 °c
- Equipped with: CE certificate
- Includes waist belt
