Flow divider, 8 way, 6,5-30 l/min

Flow divider, 8 way, 6,5-30 l/min

Technical Properties:

• Application: for An equivalent distribution of An oil current. (For example for six synchronous ongoing cylinders)
• Version: 8 way

Technical specifications:

• Item number: 9D0831
• Group: 1
• Min. volume flow: 6,5 l/min
• Max. volume flow: 30 l/min
• Max. pressure: 220 bar
• Section contents: 5,9 cc
• Number of sections: 8
• Speed: 6500 RPM
• Size R1: 1/2" BSP
• Size R2: 3/8" BSP
• Size A: 60,5 mm
• Size L: 822 mm
• Exact measurements: see attachment
